DAMPERS/PULLEYS

damper 2a.jpg

Objective:

  • Bore Diameter:        0.7433" / 18.88mm

  • Surface Finish:        22 Ra / 0.55mm Ra

  • Roundness:             0.0005" / 0.013mm

Achievement:

  • Bore Size Control:   > 2.0 Cpk

  • Surface Finish:        < 11 Ra / 0.27mm Ra

  • Roundness:             < 0.0001" / 0.0025mm

  • Cycle Time:             < 18 seconds

Pulley

CPU = 1.7¢ per piece

Objective:

  • Bore Diameter:        1.099" / 27.91mm

  • Bore Length:            2.125" / 53.98mm

  • Surface Finish:         64 Ra / 1.6mm Ra

  • Roundness:              0.0005" / 0.013mm

Achievement:

  • Bore Size Control:   > 2.0 Cpk

  • Surface Finish:        < 20 Ra / 0.5mm Ra

  • Roundness:             < 0.0002" / 0.005mm

  • Cycle Time:             < 16 seconds

Engine Damper

CPU = 1.9¢ per piece

damper 3.jpg

Objective:

  • Bore Diameter:        1.043" / 26.49mm

  • Bore Length:            1.529" / 38.84mm

  • Surface Finish:         125 Ra / 3.2mm Ra

Achievement:

  • Bore Size Control:   > 2.0 Cpk

  • Surface Finish:        < 32 Ra / 0.8mm Ra

  • Cycle Time:             < 14 seconds


Damper

CPU = 1.8¢ per piece

damper brochure 080720.png
pulley 5.jpg

Objective:

  • Bore Diameter:        1.481" / 37.62mm

  • Bore Length:            1.574" / 39.98mm

  • Surface Finish:         50 Ra / 1.25mm Ra

Achievement:

  • Bore Size Control:   > 2.0 Cpk

  • Surface Finish:        < 40 Ra / 1.0mm Ra

  • Cycle Time:             < 19 seconds

Crankshaft Pulley

CPU = 1.8¢ per piece

Accu-Cut pre-assembles, qualifies, and demonstrates

proof-of-principle for all tooling at no cost to you.

Contact us to learn more.

  • Engineered to your specific applications

  • Turnkey automation

  • Easily retooled for new applications

  • Built to last 30+ years

  • It can be yours for as little as 2.5¢ per part

  • Click HERE to learn more about Accu-Cut machines
