CNC Turnkey Systems
Why Accu-Cut CNC Turnkey Systems?
Accu-Cut machines are made-to-order, specifically engineered for your unique application. They are modular “automotive duty” machines, built to run 365 days/year and last 20+ years.
Accu-Cut machines are fully customizable to meet your needs. We will recommend the best possible machine configuration to meet your application requirements while keeping to your budget.
Accu-Cut machines are flexible and can be built to handle multiple families of parts with the appropriate change parts. Our machine and fixture solutions are designed to accommodate your production needs while minimizing changeover time.
In addition, Accu-Cut machines can be retooled to handle new applications as older applications reach the end of their lifecycle. Accu-Cut has also retooled over 25 competitor machines (both honing and bore sizing) to utilize our superior technology to bring these machines up to Accu-Cut standards, saving customers time and money to launch production.
| Part length range: | 0.5mm (0.02”) to 500mm (20.0”) |
| Bore size range: | 1.0mm (0.040”) to 200.0mm (8.0”) |
| Parts per cycle: | 1 to 10+ |
| Spindles (tool stations): | 1 to 16+ |
| Spindle head motors: | 1 to 6+ |
| Load/unload: | Manual, pick-n-place, or robot with conveyor, bowl feeder, and magazine/tray options |
| Feed: | Ball screw driven with encoder or servo feedback |
| Gaging: | Pre-process, poke-yoke, in-process, and post-process gaging options with data capture/export and analysis with auto audit cycles |
| Fixtures: | Rigid, semi-rigid X-Y floating, or gimbaled |
| Operator safety: | Interlocked barrier guarding with e-stops and optional light curtain |
| Machine safety: | Auto torque sensing, overload protection and poka-yoke crash prevention |
| Controls: | Allen-Bradley or Siemens |
| Filtration system: | Filter bag, cyclonic filter, magnetic separator, or paper-magnetic options with pump and tank |
| Lubrication: | Automatic lube option with PLC control and monitoring |
| Tool adjustment: | Automatic tool compensation option and quick tool change option |
All Accu-Cut Machines Receive Lifelong Technical Support
Accu-Cut tools and machines have a 40+ year history of providing statistically capable results at a low per piece cost. If you want to learn more about how Accu-Cut can provide you with a cost effective, turn-key bore sizing solution, please feel free to contact our customer service team.
Did you know?
- Accu-Cut machines played a critical role in Ford’s initiative to install airbags in all of their automobiles back in 1989
- Accu-Cut diamond bore sizing machines have replaced million dollar traditional honing and grinding machines at a fraction of the cost
- There are 30+ year old Accu-Cut machines that are still in service today
- Accu-Cut connecting rod machines are the industry standard with over 20 machines worldwide that produce a total of 30M+ parts per year
