WHY DIAMONDS?

Accu - cut tools-621.png

Lowest Cost Per Unit (CPU)

Diamonds maximize process capability with the highest Cp/Cpk levels (> 27 Cp / > 17 Cpk) and the lowest Cost Per Unit (as low as $0.001).

Knoop scale graph 2.0 102920.PNG

Accu-Cut pre-assembles, qualifies, and demonstrates

proof-of-principle for all tooling at no cost to you.

​

Contact us to learn more.

Accu - cut tools-621.png

Highest Process Stability


Accu-Cut Diamond Tools have the Highest Stability Factor and also eliminate scrap.

Process Capability

3.5% of tolerance


Size

Upper Limit:     20.0025 mm

Mean Size:       19.9975 mm

Lower Limit:     19.9925 mm

Process Performance

3.5% of tolerance

Cp: 27.78

Hydraulic Steering Sleeve

Size Tolerance: +/- 0.005 mm

Turbocharger Push Rod Bores

_MG_8916 2.jpg
reamer 2.jpg
reamer HSK holder.jpg
_MG_8913 2.png

Automotive Connecting Rod Crank Bore

cp 6.176.PNG

Automotive Rocker Arm

cp 4.0461.PNG

The Benchmark of Bore Quality

Diamonds produce and maintain the longest trends in SPC.

​

  • Size:                     < 1µm

  • Surface Finish:     < 0.08µm

  • Straightness:        < 0.50µm

  • Cylindricity:           < 1µm

Cylidricity graph 01.png
Roundness graph 01.png
Ra graph 3.5 uin.png
Ra graph 3.5 uin 03.png

Surface Finish: 3.5 µin / 0.089 µm

reamer 1.jpg
